Advanced Techtronix transmissions are built for durability and patented controllability, while extending tire and brake life up to 50%
Fully sealed wet disc brakes virtually eliminate brake maintenance and often last the life of the truck. Premium force-cooled wet disc brakes are standard on GP100-120VX models and optional on GP080-090VX models.
On-demand hydraulic system featuring Accutouch mini-lever controls pumps oil only when required, reducing fuel consumption
Full venting package draws air into the engine compartment from higher on the truck to enhance airflow and avoid radiator clogging
For applications requiring the use of attachments; Yale® attachment ready models are available with a factory modified front end, which allow for seamless truck and Bolzoni Auramo attachment interface.
Ergonomic operator compartment includes optimized step height with non-slip tread, soft touch contoured hand grip and infinitely adjustable steer column
ALL engines feature Yale® Flex Performance Technology™, selectable performance modes that provide the flexibility to maximize fuel economy or productivity to match application requirements
On-demand cooling system matches cooling fan speed to engine temperature, maintaining optimum engine and transmission temperatures, virtually eliminating the possibility of overheating
Combi-cooler contains an individual oil cooler to maximize transmission heat dissipation
Powertrain combinations include PSI 4.3L V6 LPG, Kubota 3.8L LPG / Dual Fuel / DOC diesel, and turbo diesel engines
Capacity: |
8,000 – 12,000 lbs |
Max Height: |
310 |
Max Weight: |
12000 lbs |
Series Title: |
GP080-120VX |
Type: |
Veracitor® Pneumatic Tire Lift Truck |
Weight: |
lbs |
Model | Model Designation | Load Capacity (lbs.) | Engine | Transmission | Maximum Travel Speed (mph) | Maximum Lift Speed (ft/min) |
---|---|---|---|---|---|---|
GP080VX | Internal Combustion Trucks | 8000 | Kubota 3.8L LPG, Kubota Turbocharged 3.8L Diesel, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel, PSI 4.3L LPG | Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed | 16 | 125 |
GP090VX | Internal Combustion Trucks | 9000 | Kubota 3.8L LPG, Kubota Turbocharged 3.8L Diesel, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel, PSI 4.3L LPG | Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed | 16 | 125 |
GP100VX | Internal Combustion Trucks | 10000 | Kubota 3.8L LPG, Kubota Turbocharged 3.8L Diesel, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel, PSI 4.3L LPG | Electronically Controlled Powershift 2 Speed, Techtronix100X Electronic 2 Speed | 14.8 | 102 |
GP110VX | Internal Combustion Trucks | 11000 | Kubota 3.8L LPG, Kubota Turbocharged 3.8L Diesel, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel, PSI 4.3L LPG | Electronically Controlled Powershift 2 Speed, Techtronix100X Electronic 2 Speed | 14.7 | 102 |
GP120VX | Internal Combustion Trucks | 12000 | Kubota 3.8L LPG, Kubota Turbocharged 3.8L Diesel, Kubota 3.8L DOC Diesel, Kubota 3.8L Dual Fuel, PSI 4.3L LPG | Electronically Controlled Powershift 2 Speed, Techtronix100X Electronic 2 Speed | 14.7 | 102 |
