Yale GP170-190VX

IC Pneumatic Tire


Need Assistance?

Let us help you find what you need.

Tough for heavy duty Applications


Rugged powertrain and computer-controlled engine and transmissions paired with robust clutch packs and strong gears make the GP170-190VX   dependable. Thanks to its innovative cooling system and extensive on-board diagnostics, the trucks require less maintenance but also are designed for easy serviceability.

The GP170-190VX series excels in heavy duty applications and is geared to minimize your cost of acquisition without compromising performance. Ergonomically designed with an adjustable steering column and full-suspension vinyl seat; it reduces operator fatigue and improves productivity.



Tough for heavy duty Applications


Rugged powertrain and computer-controlled engine and transmissions paired with robust clutch packs and strong gears make the GP170-190VX   dependable. Thanks to its innovative cooling system and extensive on-board diagnostics, the trucks require less maintenance but also are designed for easy serviceability.

The GP170-190VX series excels in heavy duty applications and is geared to minimize your cost of acquisition without compromising performance. Ergonomically designed with an adjustable steering column and full-suspension vinyl seat; it reduces operator fatigue and improves productivity.



Features
Specifications
Copy Set

Features

Yale's ERGOCAB™ sets new standards for visibility and comfort for both open and enclosed compartments.

The 47.3" (1200mm) Hook Type Standard Taper Pallet Forks streamline palletized jobs, enhancing uptime and increasing productivity.

Ergonomic comfort in the spacious open operator compartment is one of the keys to exceptional productivity.

Exceptional travel and lift speeds meet the demands of tough applications where steel machinery and fabricated metal are moved and various attachment usages is required.

Specifications

Capacity:
17000 - 19000 lbs
Max Height:
234
Max Weight:
19000 lbs
Series Title:
GP170-190VX
Type:
Pneumatic Tire Forklifts
Weight:
lbs

ModelTable

Model Model Designation Load Capacity (lbs.) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
GP175VX Internal Combustion Trucks 17500 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Techtronix 332 - 3 Speed 13.3 86
GP170VX Internal Combustion Trucks 17000 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Techtronix 332 - 3 Speed 13.4 88
GP190VX Internal Combustion Trucks 19000 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Techtronix 332 - 3 Speed 13.3 78
GP170SVX Internal Combustion Trucks 17000 Standard: PSI 4.3L V6 LPG Optional: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L High Output Tier 4 Final Turbodiesel Standard: 2-Speed Powershift Optional: 3-Speed Techtronix 332 15.0 84**
